Sensing distance 3m
Sensing target Opaque material of min. Ø60mm
Light source Red LED(660nm)
Response time Max. 20ms
Power supply 24-240VAC~ ±10% 50/60Hz, 24-240VDC ±10%(ripple P-P: max. 10%)
Current consumption Max. 3VA
Sensitivity adjustment Sensitivity adjuster
Operation mode Light ON/Dark ON(set by switch)
Control output Relay
Connection type Terminal block type
Environment_Ambient illumination Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination)
Environment_Ambient temperature -20 to 55℃, storage: -25 to 70℃
Protection structure IP66
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Material Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial,
Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum
Accessories_Individual Reflector(MS-3)
Accessories_Common Adjuster driver, Fixing bracket, Bolts, Nuts
Weight Approx. 148g
